Palmer Wahl TC801 | Type K Immersion Probe | 10 in Shank, 1600 °F

Part Number : TC801

Palmer Wahl's TC801 is a Type K immersion probe without a handle, made for fluids, corrosive mixtures, solder baths and viscous materials. The standard TC801 has a 10 in stainless steel shank of 1/8 in diameter; the TC801-24 extends to 24 in with a thicker 3/16 in shank. The probe is rated to 1600 °F.

Key features

10 in stainless steel shank, 1/8 in diameter
24 in variant (TC801-24) with 3/16 in shank
6 second response in boiling water
Temperature limit 1600 °F
Type K ANSI mini-connector plug

Availability: in stock

Specifications

Part Number	TC801
Brand	Palmer Wahl
Sensor	Type K thermocouple
Style	Immersion
Shank Length	10 in (24 in: TC801-24)
Shank Diameter	1/8 in (TC801-24: 3/16 in)
Shank Material	Stainless steel
Temperature Limit	1600 °F
Response Time	6 s (boiling water)
Handle	No
Connector	Type K ANSI mini-connector plug
