Palmer Wahl 124_Probe | RTD Rigid Shank Fast Surface Probe | Sealed, 900 °F
For rugged jobs that need a sealed sensor, the Palmer Wahl 124_Probe offers a rigid 4 in stainless shank with a straight tip. The shank is 0.12 in in diameter with a 0.250 in tip, the platinum RTD element is rated to 900 °F, and response on a 400 °F flat surface is 3 seconds.
Key features
- Sealed sensor for rugged applications
- Rigid straight 4 in stainless steel shank
- 0.250 in tip on a 0.12 in shank
- Delrin handle
- 124_Probe connector versions suit TM612/TM630, TM612A/TM630A, 392HP/392AHP and 392A Series meters
- Specifications
| Part Number | 124_Probe |
| Brand | Palmer Wahl |
| Sensor | Platinum RTD, sealed |
| Style | Rigid shank fast surface, straight tip |
| Shank Length | 4 in |
| Shank Diameter | 0.12 in |
| Tip Diameter | 0.250 in |
| Shank Material | Stainless steel |
| Handle | Delrin |
| Upper Temperature Limit | 900 °F |
| Response Time | 3 s (flat surface at 400 °F) |
| Connector Options | M8x1 4-pin (TM), Lemo 4-pin (TMA), 4-pin DIN (392AHP), 0.176 in bantam (392A) |
