Omron MY4-GS-R DC48, Plug In Power Relay, 48V dc Coil, 6A Switching Current, 4PDT

Name: Omron MY4-GS-R DC48, Plug In Power Relay, 48V dc Coil, 6A Switching Current, 4PDT
Brand: OMRON
SKU: MY4-GS-R DC48
Availability: OutOfStock

Part Number : MY4-GS-R DC48

Relay, plug-in, 14-pin, 4PDT, 6 A, mechanical indicator, 48 VDC

Availability: Sold out

Detailed Description
Specifications
Features

OMRON Power Relay, 14-Pin Connector, With Mechanical Switch Indicators - MY Series - MY4-GS-R DC48

Need a power-switching component that keeps up with demanding processes? Pick this power relay from OMRON. It tackles up to 2,400 switching cycles an hour, so you can trust it to fly through fast-moving control tasks. As it switches up to 180W, the device easily carries intense power loads for versatile machine control. Installation is quick and easy as the relay plugs directly into a compatible socket (such as 794-8218). Its reliably conductive silver contacts keep power flowing freely.

Features & Benefits

• Electrical service life of 200,000 operations for long-lasting setup control
• Coil power usage of 900mW minimises electrical consumption for efficient switching
• Comes with mechanical status indicators for clear position signalling
• Insulating plastic body protects against electric shocks
• Space-saving dimensions of 28 (L) x 21.5 (W) x 36mm (H) to fit into busy setups

Applications

• Electrical engineering
• Automated assembly lines
• Plastic production

How quickly does this relay switch my equipment?

It reacts in just 20ms to quickly open and close its contacts and deliver responsive switching.

Can I use this unit in extreme temperatures?

Yes, it performs in temperatures between -55°C and +70°C, so it does its job dependably in harsh environments.

Note

This product is scheduled for discontinuation. Please refer to the attached Discontinuation notice for further details.

Brand	Omron
Coil Voltage	48V dc
Contact Configuration	4PDT
Mounting Type	Plug In
Switching Current	6A
Number of Poles	4
Latching	No
Series	MY
Terminal Type	Plug In
Maximum Switching Voltage AC	250V
Maximum Switching Voltage DC	220V
Maximum Switching Current DC	6 A
Maximum Switching Current AC	6 A
Length	28mm
Coil Resistance	2.725 kΩ
Coil Power	900mW
Maximum Operating Temperature	+70°C
Minimum Operating Temperature	-55°C
Standards Met	CQC, CSA, IEC, UL
Contact Material	Silver

Relay, plug-in, 14-pin, 4PDT, 6 A, mechanical indicator, 48 VDC
