Omron MY4-GS-R AC220/240, Plug In Power Relay, 220 → 240V ac Coil, 6A Switching Current, 4PDT

Name: Omron MY4-GS-R AC220/240, Plug In Power Relay, 220 → 240V ac Coil, 6A Switching Current, 4PDT
Brand: OMRON
SKU: MY4-GS-R AC220/240
Availability: OutOfStock

Part Number : MY4-GS-R AC220/240

Relay, plug-in, 14-pin, 4PDT, 6 A, mechanical indicator, 220/240 VAC

Availability: Sold out

Detailed Description
Specifications
Features

OMRON Power Relay, Plug-In Terminals, 35g Weight - MY Series - MY4-GS-R AC220/240

For seamless switching in your industrial applications, reach for this power relay from OMRON. Its 4-pole configuration lets you control multiple circuits, saving space and boosting productivity. Silver alloy contacts hold their own against corrosion and impact for long-term use in challenging settings. You can easily mount this unit with a push-in terminal socket (264-7453) to cut down on your wiring needs by up to 60%. It has an insulation resistance of 1000MΩ, so it minimises the risk of electric shocks. Relays like this are regular fixtures in solar panels and military equipment.

Features & Benefits

• Plug-in terminal type, so you don't need complex tools to complete installation
• Transparent plastic housing lets you keep an eye on the internal components for simple status monitoring
• Weighs just 35g, so it's easy to handle during assembly and maintenance
• Maximum response time of 20ms for quick and efficient switching

Applications

• Packaging machinery
• Security systems
• Test and measurement equipment

What dielectric strength level does this power relay have?

This unit has a dielectric strength of 2kV AC, meaning it can safely handle high voltages without breaking down.

Note

This product is scheduled for discontinuation. Please refer to the attached Discontinuation notice for further details.

Brand	Omron
Coil Voltage	220 → 240V ac
Contact Configuration	4PDT
Mounting Type	Plug In
Switching Current	6A
Number of Poles	4
Latching	No
Series	MY
Terminal Type	Plug In
Maximum Switching Voltage AC	250V
Maximum Switching Voltage DC	220V
Maximum Switching Current AC	6 A
Maximum Switching Current DC	6 A
Length	28mm
Coil Resistance	15.92 kΩ
Coil Power	900mW
Contact Material	Silver
Height	36mm
Life	300000 cycles
Standards Met	CQC, CSA, IEC, UL

Relay, plug-in, 14-pin, 4PDT, 6 A, mechanical indicator, 220/240 VAC
