OMRON LY4N 24VAC | Plug-In Power Relay | 24 V AC Coil, 4PDT, 10 A

Name: OMRON LY4N 24VAC | Plug-In Power Relay | 24 V AC Coil, 4PDT, 10 A
Brand: OMRON
SKU: LY4N 24VAC
Availability: OutOfStock

Part Number : LY4N 24VAC

The OMRON LY4N 24VAC is a 4PDT plug-in power relay with a 24 V AC coil and a 10 A switching current rating. The 14-pin plug-in base comes with an LED indicator, with a coil resistance of 78 Ω (coil power 2.5 W).

Maximum switching voltage 250 V AC / 125 V DC
Maximum switching current 10 A AC / 10 A DC
Coil-to-contact isolation 2 kV AC
Dimensions 41.5 x 28 x 36 mm (L x H x D)
Non-latching operation
4 poles (4PDT)

Availability: in stock

Detailed Description
Specifications
Features
Downloads

Omron LY4N Series Power Relay, 24V AC Coil Voltage, 4PDT Contact Configuration - LY4N AC24

This power relay is designed for general-purpose applications, offering efficient control in various electrical systems. The compact relay measures 41.5mm in length, 36mm in depth, and 28mm in height, making it suitable for tight spaces. With a coil voltage of 24 V AC and a maximum switching current of 10 A, this relay excels in handling electrical loads reliably.

Features & Benefits

• Provides a maximum switching voltage of 250 V AC
• Capable of performing 200,000 electrical operations
• High voltage insulation rated at 2 kV AC
• Compact plug-in design simplifies installation and replacement
• Built with PCB pin terminals for easy mounting
• Reliable performance with low coil resistance of 78 Ω

Applications

• Utilised in automation control circuits
• Ideal for switching on/off industrial equipment
• Effective in HVAC system control
• Employed in programmable logic controllers (PLCs)
• Suitable for use in lighting control for buildings

What type of electrical loads can the relay effectively control?

This relay is designed to manage resistive and inductive loads, with a rated load capacity of up to 15 A at 110 VAC and 10 A at 24 VDC. It is particularly suitable for controlling motors and lighting circuits.

How does the relay's life expectancy influence its overall value in applications?

With an impressive mechanical life of up to 50 million operations and an electrical life of 200,000 operations, the relay provides longevity and reduces maintenance costs, making it a valuable component in automation and control systems.

What environmental conditions can the relay operate in without compromising performance?

The relay is built to function efficiently between -25 °C and +55 °C, ensuring reliable operation in various conditions commonly found in industrial environments.

Brand	Omron
Coil Voltage	24V ac
Contact Configuration	4PDT
Mounting Type	Plug In
Switching Current	10A
Number of Poles	4
Series	LY4N
Latching	No
Terminal Type	PCB Pin
Maximum Switching Voltage AC	250V ac
Maximum Switching Voltage DC	125V dc
Maximum Switching Current AC	10 A
Maximum Switching Current DC	10 A
Length	41.5mm
Coil Resistance	78Ω
Coil Power	2.5W
Height	28mm
Isolation Coil To Contact	2kV ac
Maximum Operating Temperature	+55°C
Depth	36mm

Relay, plug-in, 14-pin, 4PDT, 10 A, LED indicator, 24 VAC

OMRON LY4N 24VAC | Plug-In Power Relay | 24 V AC Coil, 4PDT, 10 A
