Omron LY2 100/110VDC, Plug In Power Relay, 110V dc Coil, 10A Switching Current, DPDT

Part Number : LY2 100/110VDC

Availability: Sold out

Detailed Description
Specifications

Omron LY2 Series Power Relay, DPDT Contact Configuration, 110V DC Coil Voltage - LY2 DC100/110

This power relay is designed for general-purpose applications where performance and reliability are essential. With a coil voltage of 110V DC, it meets a variety of industrial needs. Its robust design and multiple functionalities make it suitable for use in electrical and mechanical fields, facilitating seamless operations in automation and control systems.

Features & Benefits

• DPDT configuration for versatile switching options
• Supports a switching current of 10A for efficient functionality
• Operates across a wide temperature range for adaptability
• Equipped with PCB pin terminals for straightforward installation
• Provides isolation between coil and contact to enhance safety
• Long operational life minimises maintenance requirements

Applications

• Utilised in control panels for automation systems
• Employed in power distribution
• Suitable for electrical devices requiring reliable switching
• Appropriate for circuit modifications in machinery

What is the main function of this relay?

It serves as an electromechanical device to switch circuits on and off as needed.

How can I install it in my existing setup?

Installation involves connecting the PCB pins to the relevant circuit points with minimal effort.

Is it compatible with other control systems?

Yes, it can be integrated into various automation systems due to its DPDT configuration.

What maintenance is required for reliable operation?

Regular inspections and maintaining clean connections are recommended for optimal performance.

Can it withstand high-voltage environments?

Yes, it is designed to handle significant voltages, ensuring safe operation in challenging conditions.

Brand	Omron
Coil Voltage	110V dc
Contact Configuration	DPDT
Mounting Type	Plug In
Switching Current	10A
Number of Poles	2
Series	LY2
Latching	No
Terminal Type	PCB Pin
Maximum Switching Voltage AC	250V ac
Maximum Switching Voltage DC	125V dc
Length	21.5mm
Coil Resistance	3750Ω
Coil Power	900mW
Standards Met	CE, CSA
Contact Material	Silver Alloy
Height	28mm
Isolation Coil To Contact	2kV ac
Depth	36mm
Maximum Operating Temperature	+55°C
