OMRON G7J-4A-T 24VDC | Panel Mount Power Relay | 24 V DC Coil, 4PST-NO, 25 A

Name: OMRON G7J-4A-T 24VDC | Panel Mount Power Relay | 24 V DC Coil, 4PST-NO, 25 A
Brand: OMRON
SKU: G7J-4A-T 24VDC
Availability: OutOfStock

Part Number : G7J-4A-T 24VDC

This OMRON G7J-4A-T 24VDC relay pairs a 24 V DC coil with 4PST-NO contacts rated at 25 A. Part of the G7J series, the G7J-4A-T 24VDC is a non-latching relay specified with panel mounting and quick-connect terminals.

288 Ω coil resistance
Switching power up to 5.5 kVA (AC) / 750 W (DC)
Works in ambient temperatures −25 °C to +60 °C
Size: length 51.5 mm, depth 34.5 mm, height 64 mm
Listed application: general purpose

Availability: in stock

Detailed Description
Specifications

PCB Mounting & Screw Terminal - Power Relays - G7J Series

High capacity, high dielectric strength, multi-pole relays ideal for 3-phase motor control applications and resistive loads
No contact chattering for momentary voltage drops up to 50% of rated voltage
Withstands more than 4kV between contacts that are of different polarity and between the coil and contacts
Flame-resistant material (UL94V-0)
Push-to-test button lets user check contact operation
PCB mounted, screw terminal or quick connect types available

Approvals

UL; CSA

Brand	Omron
Coil Voltage	24V dc
Contact Configuration	4PST-NO
Mounting Type	Panel Mount
Switching Current	25A
Number of Poles	4
Latching	No
Series	G7J
Terminal Type	Quick Connect
Length	51.5mm
Coil Resistance	288Ω
Depth	34.5mm
Maximum Operating Temperature	+60°C
Minimum Operating Temperature	-25°C
Height	64mm
Maximum Switching Power AC	5.5 kVA
Maximum Switching Power DC	750 W
Application	General Purpose
