Name: Omron G6QE-1A DC5, PCB Mount Power Relay, 5V dc Coil, 36A Switching Current, SPST
Brand: OMRON
SKU: G6QE-1A DC5
Availability: OutOfStock

Omron G6QE-1A DC5, PCB Mount Power Relay, 5V dc Coil, 36A Switching Current, SPST

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron G6QE-1A DC5, PCB Mount Power Relay, 5V dc Coil, 36A Switching Current, SPST

Part Number : G6QE-1A DC5

Availability: Sold out

Detailed Description
Specifications

Miniature and Low Height Single-pole Power Relay with 36A Switching Current

High switching current of 36 A@250 VAC and 10,000 operations, 30 A@250 VAC and 100,000 operations in a miniature package
Achieved 10-kV impulse withstand voltage (between coil and contacts)
Power consumption reduced to 12% compared with rated coil consumption by lowering the applied voltage to the coil after applying nominal voltage for 100 ms relay operation (Reduced to 35% from rated coil voltage)

Brand	Omron
Coil Voltage	5V dc
Contact Configuration	SPST
Mounting Type	PCB Mount
Switching Current	36A
Number of Poles	1
Series	G6QE
Latching	No
Terminal Type	PCB Pin
Maximum Switching Voltage AC	277V ac
Maximum Switching Current AC	36 A
Length	30.5mm
Coil Resistance	17.9Ω
Coil Power	1.4W
Depth	16mm
Height	20.5mm
Contact Material	Silver Alloy
Minimum Operating Temperature	-40°C
Maximum Operating Temperature	+85°C
Maximum Switching Power DC	1400mW
