OMRON G6KU-2F-Y DC4.5 | Surface Mount Latching Signal Relay | 4.5 V DC Coil, DPDT, 1 A
Built around a 4.5 V DC coil, the OMRON G6KU-2F-Y DC4.5 is a latching signal relay for surface mount assembly with DPDT contacts rated at 1 A. The G6KU-2F-Y DC4.5 is listed with maximum switching voltages of 125 V AC and 60 V DC and a maximum DC switching power of 30 W.
- Coil voltage: 4.5 V DC
- Contact configuration: DPDT
- Latching type
- Maximum switching voltage: 125 V AC / 60 V DC
- Maximum switching power: 30 W DC / 37.5 VA AC
- Maximum switching current: 1 A AC, 1 A DC
- Detailed Description
- Specifications
Omron G6K Series
Fully sealed construction
Low power consumption of approximately 100mW
Incorporates a unique terminal structure with high infra-red irradiation efficiency, ensuring excellent soldering characteristics
G6K-2F types conform to FCC Part 68 (1500V for 10x160μs)
G6K-2G-Y, G6K-2F-Y & G6KU-2F-Y types conform to Bellcore specifications (2500V for 2x10μs)
Approvals

| Brand | Omron |
| Coil Voltage | 4.5V dc |
| Contact Configuration | DPDT |
| Mounting Type | Surface Mount |
| Switching Current | 1A |
| Maximum Switching Current DC | 1 A |
| Maximum Switching Voltage AC | 125V ac |
| Maximum Switching Voltage DC | 60V dc |
| Maximum Switching Power DC | 30 W |
| Length | 10 mm (0.394 in) |
| Latching | Yes |
| Depth | 7.8 mm (0.307 in) |
| Height | 5.2 mm (0.205 in) |
| Dimensions | 10 x 5.2 x 7.8 mm (0.394×0.205×0.307 in) |
| Terminal Type | Surface Mount |
| Application | Signal |
| Maximum Operating Temperature | +70 °C (158 °F) |
| Maximum Switching Current AC | 1 A |
| Maximum Switching Power AC | 37.5VA |
| Life | 10000000 (Electrical) cycles, 50000000 (Mechanical) cycles |
