OMRON G6AK-274P-ST-US 24DC | Latching Signal Relay | 24 V DC Coil, DPDT, 500 mA, PCB Mount
With a 24 V DC coil, the OMRON G6AK-274P-ST-US 24DC is a DPDT latching signal relay for PCB mounting that switches up to 500 mA. The G6AK-274P-ST-US 24DC is listed with a maximum switching voltage of 250 V AC / 220 V DC and switching power up to 60 W DC. On the coil side, the G6AK-274P-ST-US 24DC listing gives a power of 180 mW.
- Dimensions: 20.2 x 10.1 x 8.4 mm
- Terminals: through hole
- Max switching current: 500 mA AC / 500 mA DC
- Contact material: gold-plated
- Life: 500,000 operations (electrical)
- Listed application: signal
- Detailed Description
- Specifications
- Downloads
G6A Series DPCO Latching
Low magnetic leakage
Impulse withstand voltage of 1500V
Ideal for telecommunications equipment
Approvals
| Brand | Omron |
| Coil Voltage | 24V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Switching Current | 500mA |
| Maximum Switching Current DC | 500 mA |
| Maximum Switching Voltage AC | 250V ac |
| Maximum Switching Voltage DC | 220V dc |
| Maximum Switching Power DC | 60 W |
| Length | 20.2 mm (0.795 in) |
| Latching | Yes |
| Depth | 10.1 mm (0.398 in) |
| Height | 8.4 mm (0.331 in) |
| Dimensions | 20.2 x 10.1 x 8.4 mm (0.795×0.398×0.331 in) |
| Terminal Type | Through Hole |
| Application | Signal |
| Coil Power | 180mW |
| Maximum Switching Current AC | 500 mA |
| Contact Material | Gold Plated |
| Electrical Life | 500000 Operations |
