OMRON G5PZ-1A DC24 | PCB Mount Non-Latching Relay | 24 V DC Coil, 16 A, SPST

Name: OMRON G5PZ-1A DC24 | PCB Mount Non-Latching Relay | 24 V DC Coil, 16 A, SPST
Brand: OMRON
SKU: G5PZ-1A DC24
Availability: OutOfStock

Part Number : G5PZ-1A DC24

This 24 V DC version of the OMRON G5PZ-1A DC24 is a PCB-mount non-latching relay offering SPST contacts and 16 A switching current. Coil resistance is 272 Ω with 530 mW coil power, and coil-to-contact isolation is 10 kV.

SPST contact configuration, 1 pole
Number of coils: single
OMRON G5PZ series

Availability: in stock

Detailed Description
Specifications
Downloads

The Omron G5PZ series for compact PCB power relay use for home conditioners and appliances. Switching current is 20 A and enclosure rating is flux protection.

10.5 mm (W) slim size and 1 pole 16 A/20 A switching capability
High sensitivity of 530 mW coil consumption and further saving energy with holding voltage 50%
Min. 6.4 mm of insulation distance and 10 kV impulse withstand voltage (between coil and contact

Brand	Omron
Coil Voltage	24V dc
Contact Configuration	SPST
Mounting Type	PCB Mount
Switching Current	16A
Number of Poles	1
Series	G5PZ
Coil Resistance	272 Ω
Coil Power	530mW
Isolation Coil To Contact	10kV
Number of Coils	Single
