OMRON EJ1N-TC4B-QQ | DIN Rail PID Temperature Controller | 48 x 48 mm, PNP Output, 24 V DC

Name: OMRON EJ1N-TC4B-QQ | DIN Rail PID Temperature Controller | 48 x 48 mm, PNP Output, 24 V DC
Brand: OMRON
SKU: EJ1N-TC4B-QQ
Availability: OutOfStock

Part Number : EJ1N-TC4B-QQ

The OMRON EJ1N-TC4B-QQ is a 48 x 48 mm DIN-rail PID temperature controller from the EJ1 series, fitted with four PNP outputs and powered from 24 V DC; the universal input supports platinum RTD, Pt100, thermocouple and analogue sensors and signals.

Control: ON/OFF, PID, 2-PID
Number of inputs: 4
Terminals: screw terminal block
Mounting: DIN rail
Supply voltage: 24 V DC

Availability: in stock

Detailed Description
Specifications
Downloads

Omron EJ1 Series Controller, PNP Output, 24V DC Supply Voltage - EJ1N-TC4B-QQ

This controller is a robust PID controller, designed for precise temperature management across a multitude of industrial applications. With a compact size of 48 x 48 mm, it efficiently integrates into various systems. Operating on a supply voltage of 24V DC, this device accommodates input from universal sensors, including thermocouples and platinum resistance thermometers, enabling wide-ranging temperature measurement from -200 to +2300 °C.

Features & Benefits

• PNP output type enhances compatibility with various systems
• Capable of controlling temperatures from -200 to +2300 °C
• Equipped with universal input for diverse sensor compatibility
• PID control ensures accurate temperature regulation
• Mounts easily on DIN rail for efficient installation

Applications

• Used with thermocouples and platinum resistance thermometers
• Suitable for industrial automation systems requiring precise temperature control
• Ideal for processes requiring monitoring within a temperature range of -10°C to +55°C
• Used with screw terminals for reliable and easy wire management

How does the PID control feature enhance temperature accuracy?

The PID control method continuously calculates an error value as the difference between a setpoint and a process variable, adjusting the controller output to maintain the desired temperature with precision.

What types of sensors can be connected for temperature measurement?

This controller accommodates a range of sensors, including universal inputs, thermocouples, and platinum resistance thermometers, providing versatility for various applications.

What is the significance of the DIN rail mounting for this device?

DIN rail mounting facilitates straightforward installation and integration into existing systems, allowing for organised wiring and reducing installation time in industrial setups.

What connection type does this controller utilise for input and output?

It uses screw terminal blocks for both inputs and outputs, ensuring a firm and secure connection that is easy to wire and maintain.

Brand	Omron
Output Type	PNP
Supply Voltage	24 V dc
Size	48 x 48mm
Number of Inputs	4
Number of Outputs	4
Control Type	ON/OFF, PID, 2-PID Controller
Series	EJ1
Mounting Type	DIN Rail
Input Type	Universal, Platinum Resistance Thermometer, PT100, Thermocouple, Analogue
Termination Type	Screw terminal block

OMRON EJ1N-TC4B-QQ | DIN Rail PID Temperature Controller | 48 x 48 mm, PNP Output, 24 V DC

DOWNLOAD CATALOG

EJ1N-TC4B-QQ Brochure - Temperature Control Units A700000014360061
