Omron E2A-S12KS04-M1-B1, Inductive Threaded Barrel Proximity Sensor, M12, 4 mm Detection, PNP NO, 12 → 24 V dc

Name: Omron E2A-S12KS04-M1-B1, Inductive Threaded Barrel Proximity Sensor, M12, 4 mm Detection, PNP NO, 12 → 24 V dc
Brand: OMRON
SKU: E2A-S12KS04-M1-B1
Availability: OutOfStock

Part Number : E2A-S12KS04-M1-B1

Availability: Sold out

Detailed Description
Specifications
Downloads

Omron E2A Series Proximity Sensor, 4mm Detection Range, 12 to 24V Supply Voltage - E2A-S12KS04-M1-B1

This proximity sensor is designed for precise detection in industrial automation applications. The inductive sensing technology allows it to detect metallic objects without physical contact, enhancing safety and durability. Measuring 48mm in length, this sensor operates over a detection range of 4mm, making it ideal for confined spaces.

Features & Benefits

• Inductive sensor technology ensures reliable metal detection
• Detects objects in wet environments with IP67 and IP69K protection
• Stainless steel housing enhances durability and corrosion resistance
• PNP output configuration facilitates easy integration into existing systems
• High-frequency operation up to 1000Hz for fast response
• Wide supply voltage range of 12 to 24V DC for versatile applications

Applications

• Utilised in automated assembly machines for precise object detection
• Employed in packaging equipment for non-contact sensing of items
• Ideal for use in conveyor systems to monitor product placement
• Suitable for positioning feedback in robotic
• Effective for level detection in tanks and silos

What is the temperature range for operation and storage?

This device operates effectively in a temperature range of -40°C to +70°C, ensuring functionality in diverse environmental conditions. It can be stored safely from -40°C to +85°C, accommodating various operational needs.

How does the sensor perform in environments with high humidity?

The sensor is rated to function in 35% to 95% relative humidity, making it suitable for humid manufacturing settings while maintaining reliable performance.

What type of output configuration is available for integration?

The device features a PNP output configuration, which allows for straightforward connection to control systems and devices in industrial applications. This setup enhances compatibility with various automation technologies.

Brand	Omron
Thread Size	M12
Sensor Technology	Inductive
Body Style	Threaded Barrel
Detection Range	4 mm
Digital Switching Output Type	PNP
Output Function	NO
Connection Type	M12
Supply Voltage	12 → 24 V dc
Length	48mm
Mounting Type	Flush Mount
Housing Material	Stainless Steel
Maximum DC Voltage	32V
Minimum Operating Temperature	-40°C
Maximum Operating Temperature	+70°C
Shielding	Shielded
Standards Met	IEC 60529
Switching Current	200 mA
Switching Frequency	1 kHz
Series	E2A

Omron E2A-S12KS04-M1-B1, Inductive Threaded Barrel Proximity Sensor, M12, 4 mm Detection, PNP NO, 12 → 24 V dc

DOWNLOAD CATALOG

E2A-S12KS04-M1-B1 Brochure - Inductive Proximity Sensors A700000013143142
