Name: Omron D4N1A62, D4N Series Roller Lever Top Plunger, NO/NC, IP67, DPST
Brand: OMRON
SKU: D4N1A62
Availability: OutOfStock

Omron D4N1A62, D4N Series Roller Lever Top Plunger, NO/NC, IP67, DPST

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron D4N1A62, D4N Series Roller Lever Top Plunger, NO/NC, IP67, DPST

Part Number : D4N1A62

Availability: Sold out

Detailed Description
Specifications
Downloads

D4N Series Safety Limit Switch PG13.5

Replacement for Omron D4D-N Series limit switches. Functionality is unchanged but body length is increased by 4mm. The change in body length does not affect the actuator position.

N/C for safety circuit and N/O for control circuit (SPDT)
Contact rating 10A continuous
Head may be located in choice of 4 positions
IP67 protection rating
PG13.5 conduit entry
Ambient operating temperature -30 to +70°C
Conforms to Machinery Directive and Low Voltage Directive

Standards

TUV EN60947-5-1 (approved direct opening), UL508 CSA C22.2 No.14, CCC (CQC) GB14048.5, EN50047, EN1088 (slow action models only).

Brand	Omron
Actuator Type	Roller Lever
Pole and Throw Configuration	DPST
Normal State Configuration	NO/NC
IP Rating	IP67
Connection Type	PG13.5
Series	D4N
Length	31mm
Width	31.5mm
Depth	92mm
Mounting Orientation	Side
Mechanical Life	15000000Operations

Omron D4N1A62, D4N Series Roller Lever Top Plunger, NO/NC, IP67, DPST

DOWNLOAD CATALOG

D4N1A62 Omron Machine Safety 0900766b814c686b
