OMRON D2VW-5L1-1(D)(CHN) | Hinge Lever Micro Switch | 5 A @ 250 V ac, SPDT, Solder Terminal
Rated 5 A at 250 V ac, the OMRON D2VW-5L1-1(D)(CHN) pairs a hinge lever actuator with solder terminals in an SPDT micro switch. This hinge lever version is rated for ambient temperatures of -40 to +85 °C. The switch body carries an IP67 rating.
- Contact configuration: SPDT (single-pole double-throw)
- Silver alloy contacts
- Operating force: 1.18 N; release force: 0.15 N
- Rated for 10 million operations (mechanical)
- Contact rating: 5 A at 250 V ac
- Detailed Description
- Specifications
Omron Subminiature Sealed (5 A)
Sealed to IEC IP67 (wire lead type)
RoHS compliant
Switches up to 5A @ 250Vac
Contact configuration: SPDT
Approvals
Approvals
| Brand | Omron |
| Actuator Type | Hinge Lever |
| Terminal Type | Solder |
| Contact Configuration | SPDT |
| IP Rating | IP67 |
| Contact Current Rating | 5 A @ 250 V ac |
| Minimum Operating Temperature | -40 °C (-40 °F) |
| Maximum Operating Temperature | +85 °C (185 °F) |
| Contact Material | Silver Alloy |
| Mechanical Life | 10000000Operations |
| Operating Temperature Range | -40 → +85 °C (-40 to 185 °F) |
| Operating Force | 1.18 N |
| Release Force | 0.15N |
