OMRON CP2E-N30DR-D | CP2E Network Type Compact PLC | 18 DI, 12 Relay DO, 24 VDC

Name: OMRON CP2E-N30DR-D | CP2E Network Type Compact PLC | 18 DI, 12 Relay DO, 24 VDC
Brand: OMRON
SKU: CP2E-N30DR-D
Availability: OutOfStock

Part Number : CP2E-N30DR-D

The OMRON CP2E-N30DR-D is a CP2E Network Type compact PLC with 18 digital inputs and 12 relay outputs, a 24 VDC power supply and 10 kStep program memory.

Digital I/O: 18 inputs, 12 relay outputs
Power supply: 24 VDC
Program memory: 10 kStep
Ethernet; RS-485 interface
Dimensions: 130 x 80 x 110 mm, panel mount

Availability: in stock

Detailed Description
Specifications
Features
Downloads

CP2E series compact PLC - Network type,18 DI, 12DO,Relay output,Power supply 24 VDC,10 kStep Program memory

Two built-in Ethernet ports with Ethernet switching function:
Ready for Machine to Machine communication (CP2E-N type)
Up to three serial ports: Open connectivity to serial devices (CP2E-N type)
Four-axis positioning function with linear interpolation (CP2E-N type)
Battery-free operation and backup reduce maintenance
Function blocks and structured text improve programming efficiency
Operating temperature range from -20 to 60 °C for reliable use in special applications
Input/output terminal LED indicators for quick troubleshooting

Brand	Omron
Manufacturer Series	CP2E
Number of Inputs	18
Output Type	Relay
For Use With	CP2E Series
Input Type	Digital
Number of Digital Inputs	18
Number of Outputs	12
Voltage Category	24 V dc
Number of Digital Outputs	12
Network Type	Ethernet
Interface	RS-485
Dimensions	130 x 80 x 110 mm
Display Included	Yes
Program Capacity	8 kB
Depth	110mm
Programming Language Used	Ladder Diagram
Mounting Type	Panel Mount
Width	80mm
Length	130mm
