OMRON B3S-1002P | Button Tactile Switch | 6.6 x 6 mm, 2.26 N, IP64
Part Number : B3S-1002P
This SPST black button tactile switch from OMRON, part B3S-1002P, operates at 2.26 N and is listed as IP64. The B3S-1002P is specified with a mechanical life of 300,000 operations and an operating temperature range of -25 to +70 °C.
- Contact rating: 50 mA at 24 V DC
- Actuator length: 0.8 mm
- Dimensions: 6.6 x 6 x 4.3 mm
For pricing, please contact our experts.
Surface Mount Tactile Switch
All switches have a contact configuration of SPST N/O
Sealed construction
Tactile feedback
Dielectric strength: >500Vac/1 min
Insulation resistance: >100MΩ (250Vdc)
Sealed for immersion washing after soldering
Suitable for reflow soldering
Reflow temperature: 235°C, 10 secs max
Tactile feedback
Dielectric strength: >500Vac/1 min
Insulation resistance: >100MΩ (250Vdc)
Sealed for immersion washing after soldering
Suitable for reflow soldering
Reflow temperature: 235°C, 10 secs max
Note
Do not use chlorinated or aqueous solvents for cleaning
