Norbar 43531 Torque Tools Digital Torque Tester, 50 → 1100Nm, 27mm Drive, ±1 % Accuracy, 1Nm Increment
The Norbar TruCheck 2 Plus 43531 is a digital torque wrench tester designed to check torque wrenches across a range of 50–1,100 N·m. It offers ±1% of reading accuracy and uses a 27 mm male hex connection. With Click, Dial and Track operating modes, up to 15 saved targets and colour-coded tolerance alerts, it supports professional torque verification in workshops and industrial maintenance environments. Supplied by General Tech Services LLC, UAE, it helps identify potential torque deviations between formal calibrations.
Part No. 43531
Contact Number: +971 6 5436933
Heavy-duty torque wrenches require regular checks to help ensure they remain within their specified limits. The Norbar TruCheck 2 Plus 43531 provides a practical way to verify wrench performance across its 50–1,100 N·m range and quickly identify readings that fall above or below the selected tolerance.
The tester has a stated accuracy of ±1% of reading and a 27 mm male hex connection. Norbar notes an accuracy specification of ±2% below 10% of range for its 1,100 N·m model; users should consult the applicable manufacturer's documentation when checking readings at the lower end of the range.
The Plus version provides three operating modes for different testing requirements. Click mode captures the first torque peak, Dial mode holds the highest peak, and Track mode displays live torque and supports zeroing. Users can save up to 15 targets with defined tolerances for repeat testing.
The colour display indicates the result at a glance: green when the reading is within tolerance, red when it is high and yellow when it is low. Measurement units and 12 languages are selectable, and test data can be transferred over USB.
A built-in Micro USB 2.0 port allows the tester to run from a compatible USB power source. Norbar also supports remote software updates, and a traceable calibration certificate is supplied.
For users who need straightforward click-wrench checks with simpler settings, consider the Norbar TruCheck 2 Basic 43530, which covers the same 50–1,100 N·m range.
Routine torque checks help identify possible deviations between formal calibration intervals. They complement, rather than replace, formal calibration where required by quality procedures or applicable standards.
Key Benefits
-
Wide torque range: Checks torque wrenches from 50–1,100 N·m.
-
±1% stated reading accuracy: Supports routine torque verification within the applicable measurement range.
-
27 mm male hex connection: Designed for compatible torque-tool connections.
-
Three operating modes: Click, Dial and Track modes accommodate different testing requirements.
-
Up to 15 saved targets: Stores target values and tolerances for repeat checks.
-
Colour-coded tolerance alerts: Green indicates in tolerance, red indicates high and yellow indicates low.
-
USB-powered operation: Runs from a compatible USB power source through Micro USB 2.0.
-
USB data transfer: Supports transferring test data to compatible systems.
-
Multilingual interface: Offers 12 selectable languages.
-
Traceable calibration certificate: Supplied with the tester.
For pricing and availability, contact General Tech Services LLC, UAE, on +971 6 5436933.
Who This Product Is Best For
-
Workshops checking heavy-duty click-type torque wrenches between formal calibrations.
-
Industrial maintenance teams verifying high-torque tools.
-
Quality-control departments checking tools against defined torque targets.
-
Calibration laboratories and tool-crib staff testing different wrench types.
-
Automotive, fleet and equipment service facilities using high-torque fasteners.
-
Professional users who need saved targets, tolerance alerts and test-data transfer.
How to Specify & Install It
-
Confirm the required torque range: Ensure the 50–1,100 N·m capacity suits the tools being tested.
-
Verify the connection: Check that the torque wrench and tester are compatible with the 27 mm male hex connection.
-
Position the tester: Secure the unit in accordance with the manufacturer's installation instructions.
-
Connect USB power: Use a compatible USB power source through the Micro USB 2.0 port.
-
Select the operating mode: Choose Click, Dial or Track according to the wrench type and test procedure.
-
Set the target and tolerance: Select a saved target or configure the required test limits.
-
Perform the test: Fit the wrench correctly and apply force smoothly according to the manufacturer's testing procedure.
-
Review and record the result: Check the measured torque and colour-coded tolerance indication. Transfer results over USB when required.
Frequently Asked Questions
What torque range does the Norbar TruCheck 2 Plus 43531 cover?
It checks torque wrenches across 50–1,100 N·m through a 27 mm male hex connection.
How accurate is the TruCheck 2 Plus 43531?
The stated accuracy is ±1% of reading. Norbar notes ±2% below 10% of range for the 1,100 N·m model, so check the manufacturer's documentation for the applicable accuracy at low readings.
What is the difference between TruCheck 2 Basic and Plus?
The Basic version focuses on straightforward click-wrench checks with simplified settings. The Plus version adds Click, Dial and Track modes, up to 15 saved targets with colour-coded tolerance alerts, 12 languages and USB data transfer.
What does each operating mode do?
Click mode captures the first torque peak, Dial mode holds the highest peak, and Track mode displays live torque and supports zeroing.
How do the colour-coded alerts work?
Green indicates a reading within tolerance, red indicates a high reading and yellow indicates a low reading.
Does the tester require batteries or mains power?
It operates from a compatible USB power source through its Micro USB 2.0 port.
Can I transfer test data to a computer?
Yes. The tester supports USB data transfer. Confirm compatibility with your computer and any software required for your workflow.
Does it include a calibration certificate?
Yes. A traceable calibration certificate is supplied.
Which model should I choose: the TruCheck 2 Basic 43530 or Plus 43531?
Both cover 50–1,100 N·m. Choose the Basic for simpler click-wrench checks or the Plus if you need multiple operating modes, saved targets and colour-coded tolerance alerts.
How can I request a price in the UAE?
Contact General Tech Services LLC to confirm current pricing and availability.
For the Norbar TruCheck 2 Plus 43531, contact General Tech Services LLC, UAE, for pricing and product assistance.
+971 6 5436933
