Part Number : 543-312B-10

The Mitutoyo 543-312B-10 Digital Indicator from Series 543 is a bore gauge-type ID-C model that conforms to ASME/ANSI standards, making it ideal for precision internal diameter measurements. With a 0.5-inch measuring range, it is perfect for small and detailed bore applications. The indicator provides outstanding accuracy and repeatability, both rated at 0.0001 inch, ensuring consistent and reliable results. Designed for industrial-grade performance, it integrates seamlessly with bore gauge systems and is well-suited for use in quality control, inspection, and machining environments.

Availability: in stock

Free Saudi Arabia shipping available

Specifications
Features
Downloads

Alarm	Low voltage, ABS composition error, overflow error, setting error
Analog/Digital	Digital
Battery Life	Standard mode: approx. 1 year, Fast mode: approx. 4.5 month
Contact point	Carbide Ball
Data hold function	Yes
Digimatic data output	Yes
Digital step	0.00005 in/0.0001 in/0.0005 in or 0.001 mm/0.01 mm
Display	LCD, character height 8 mm, 330° rotatable
GO/+/-NG judgement	Yes
Hysteresis	0.0001 Inch or 0.002 mm
Inch-Metric	Inch/Metric
Lock function	Yes
Max. permissible error	E MPE: +/-0.0001 Inch or 0.003 mm
Max. Response Speed	Unlimited
Measuring Force	¢°¤1.5 N
Model Number	ID-C112GEXB2
ON/OFF	Yes
Power Supply	1 battery CR2032
Protection	IP42
Range	0.5 Inch or 12.7 mm
Repeatability	0.0001 Inch or 0.002 mm
Scale	Electrostatic capacitance type absolute linear encoder
Series	543
Stem Dia	9.52 mm
Thread type	No.4-48UNF
Type	ASME/ANSI/AGD Standard
Type	Digital Indicator
Weight	170 g

Bore Gauge Type: Optimized for accurate internal diameter measurements.
ASME/ANSI Compliant: Meets industry standards for quality and reliability.
High Precision: 0.0001-inch repeatability and accuracy for consistent results.
Ideal Measuring Range: 0.5-inch range suited for small to medium bores.
Reliable Performance: Designed for repeatable, high-accuracy inspections.
Industrial-Grade Build: Perfect for quality control labs and shop floor environments.
