ifm EVC511, Right Angle Male 5 way M12 to Straight Female 5 way M12 Communication Cable, 3m

Name: ifm EVC511, Right Angle Male 5 way M12 to Straight Female 5 way M12 Communication Cable, 3m
Brand: ifm
SKU: EVC511
Availability: OutOfStock

Part Number : EVC511

Availability: Sold out

Detailed Description
Specifications

The ifm electronic connection cable is designed to provide exceptional performance and reliability in demanding environments. Featuring a robust construction and halogen-free materials, it caters to a wide array of applications where safety and durability are paramount. The product is engineered to withstand extreme temperatures ranging from -25°C to 90°C, ensuring it operates proficiently under strenuous conditions. Its gold-plated contacts guarantee superior electrical connectivity and resistance to corrosion, making it ideal for long-term use. The cable is also compatible with drag chains, providing flexibility and resilience for moving applications. With its IP65 to IP69K protection rating, the connection cable is well-equipped to handle moisture and dust ingress, further enhancing its suitability for industrial applications.

Resistant to oils and coolants
Permanent and reliable sealing even when mounted without tools
High protection rating for the requirements of harsh industrial environments
Vibration and shock resistant thanks to coupling ring with locking mechanism
Mec

Brand	ifm
Series	EVC
Cross Sectional Area	0.34 mm²
Number of Cores	4
Length	3 mm
Sheath Material	Polyurethane PUR
Sheath Colour	Black
Connector 1 Gender	Male
Connector 1 Number of Contacts	5
Connector 1 Orientation	Right Angle
Connector 1	M12
Connector 2 Gender	Female
Connector 2	M12
Connector 2 Orientation	Straight
Connector 2 Number of Contacts	5
