HIOKI LR5001 | Humidity Logger
Genuine Hioki LR5001 humidity logger from General Tech Services LLC, Saudi Arabia, with free Saudi Arabia shipping available.
Part No. LR5001
Product Overview
The Hioki LR5001 is a pocket-size 2-channel data logger designed to record temperature and humidity simultaneously. It provides a practical way to monitor environmental conditions continuously in locations where a single spot measurement cannot show how conditions change over time.
The LR5001 measures temperature from −40.0 to 85.0 °C and humidity from 0 to 100% RH. Temperature accuracy is ±0.5 °C from 0 to 35 °C, while humidity accuracy is ±5% RH when used with the specified LR950x sensor under the stated conditions.
Recording intervals can be set from 1 second to 60 minutes, with 15 selectable intervals. The logger stores up to 60,000 instantaneous data readings per channel. Statistical recording mode stores up to 15,000 data per channel, while STAT mode can capture maximum, minimum and average values within each recording interval.
The LR5001 has an IP54 protection rating when the sensor is connected and operates from one LR6 (AA) battery. Battery life is approximately three months when recording at one-minute intervals. The battery can be replaced while recording, and recorded data is preserved even if the battery becomes depleted.
An LR9504 humidity sensor is included. Data can be transferred to a PC using the optional LR5091 Communication Adapter or LR5092-20 Data Collector.
General Tech Services supplies genuine Hioki instruments across Saudi Arabia from its Dammam office. Share the part number, quantity and delivery location, and our team can confirm availability, accessories and pricing.
Key Benefits
- Records temperature and humidity simultaneously
- Wide temperature range from −40.0 to 85.0 °C
- Humidity measurement from 0 to 100% RH
- Stores up to 60,000 instantaneous readings per channel
- Recording intervals from 1 second to 60 minutes
- STAT mode records maximum, minimum and average values
- IP54 protection with sensor connected
- Approximately three months of operation from one AA battery at a one-minute interval
- Recorded data is preserved if the battery becomes depleted
- LR9504 humidity sensor included
Who This Product Is Best For
The Hioki LR5001 is suited to:
- Warehouse and cold-chain monitoring
- Pharmaceutical and food-storage facilities
- HVAC engineers validating environmental conditions
- Museums and archives
- Data centres and controlled storage environments
- Facilities requiring continuous temperature and humidity records
How to Install & Use It
- Confirm that the LR5001 and included or optional sensors and accessories suit the intended monitoring application.
- Read the Hioki instruction manual before first use.
- Connect the LR9504 humidity sensor and position the sensor and logger according to the operating instructions.
- Select the required recording interval and recording mode.
- Start recording and allow the logger to monitor conditions for the required period.
- Transfer recorded data to a PC using the optional LR5091 Communication Adapter or LR5092-20 Data Collector when required.
Keep the sensor positioned appropriately for the environment being monitored and follow the manufacturer's operating instructions.
Frequently Asked Questions
What is the Hioki LR5001?
The Hioki LR5001 is a pocket-size 2-channel data logger that records temperature and humidity simultaneously.
What does the LR5001 measure?
It measures temperature and humidity simultaneously using one temperature channel and one humidity channel.
What is the temperature measurement range?
The temperature range is −40.0 to 85.0 °C, with an accuracy of ±0.5 °C from 0 to 35 °C.
What is the humidity measurement range?
The humidity range is 0 to 100% RH. The stated ±5% RH accuracy applies when using the LR950x sensor under the specified conditions.
How much data can the LR5001 store?
It stores up to 60,000 instantaneous data readings per channel. Statistical recording capacity is up to 15,000 data per channel.
What recording intervals are available?
The LR5001 provides 15 selectable recording intervals from 1 second to 60 minutes.
How do I download the recorded data?
Recorded data can be transferred to a PC using the optional LR5091 Communication Adapter or LR5092-20 Data Collector.
Is the humidity sensor included?
Yes. The LR9504 humidity sensor is included with the LR5001.
Should I choose the LR5001 or the FT3701-20?
The two products are designed for different measurement requirements. Contact General Tech Services with your application details so we can confirm the appropriate Hioki model.
Does it come with warranty and support?
The LR5001 is supplied as a genuine Hioki instrument. Contact General Tech Services for current warranty information and local technical support details.
Is delivery available across Saudi Arabia?
Yes. Free Saudi Arabia shipping is available. Call +966 569 289 544 for current pricing and lead time.
