HIOKI DT4256 | DIGITAL MULTIMETER
A full-featured DT4200-series digital multimeter with dual display, direct 10A current input, and a wide -25°C to 65°C operating range for demanding electrical testing environments.
Request a quote in under a minute — call +971 6 5436933.
Model: DT4256
The Hioki DT4256 is designed for technicians who need extensive measurement functionality in a single general-purpose digital multimeter. It measures DC voltage up to 1000 V with ±0.3% accuracy, AC voltage up to 1000 V, DC and AC current up to 10.00 A, and frequency up to 99.99 kHz.
Its dual display allows voltage and frequency to be viewed simultaneously, which can be useful when diagnosing variable-speed drives or checking electrical supply conditions while monitoring other measurements. The direct 10A current input also allows routine current measurements without requiring an external clamp.
For inverter-related measurements, the built-in low-pass filter helps reduce the effect of high-frequency harmonics when measuring inverter waveforms. The DT4256 also supports a wide operating temperature range from -25°C to 65°C, making it suitable for demanding working environments.
Optional USB communications allow the DT4256 to be connected for PC-based data logging when measurement records or documentation are required. The meter measures 84 × 174 × 52 mm and weighs 390 g.
The Hioki range also includes the DT4252, providing an alternative DT4200-series multimeter for applications with different measurement requirements.
Ready to order the DT4256? Speak to our team. Call +971 6 5436933.
Key Benefits
- Full-range measurement of DC/AC voltage up to 1000 V and DC/AC current up to 10.00 A
- Frequency measurement up to 99.99 kHz
- Dual display for simultaneous voltage and frequency readings
- Direct 10A current input for routine current measurements without an external clamp
- Built-in low-pass filter for inverter waveform measurements
- Wide operating temperature range from -25°C to 65°C
- Optional USB communications for PC-based data logging
- Compact 390 g design for general electrical testing
Who This Product Is Best For
- Industrial electricians handling a wide range of electrical measurements
- Technicians who need voltage, current, and frequency measurement in one meter
- Professionals working with variable-speed drives and inverter waveforms
- Technicians working in environments with demanding temperature conditions
- Users who need optional PC-based data logging for measurement documentation
How to Use
- Select the appropriate measurement function for voltage, current, or frequency.
- Connect the test leads to the appropriate terminals for the measurement being performed.
- Use the direct 10A input when measuring current up to the specified range.
- Use the dual display to monitor voltage and frequency simultaneously when required.
- Use the low-pass filter when measuring inverter waveforms where high-frequency harmonics may affect the measurement.
- Connect the optional USB communications interface when PC-based data logging is required.
Frequently Asked Questions
What is the maximum voltage measurement range of the DT4256?
The DT4256 measures DC voltage up to 1000 V and AC voltage up to 1000 V.
What is the current measurement range of the DT4256?
It measures DC current from 60.00 mA to 10.00 A and AC current from 600.0 mA to 10.00 A.
Can the DT4256 measure frequency?
Yes. The frequency measurement range is 99.99 Hz to 99.99 kHz.
Can the DT4256 display voltage and frequency at the same time?
Yes. Its dual-display design allows voltage and frequency to be viewed simultaneously.
Does the DT4256 have a low-pass filter?
Yes. The built-in low-pass filter helps reduce the effect of high-frequency harmonics when measuring inverter waveforms.
What is the operating temperature range of the DT4256?
The DT4256 has an operating temperature range of -25°C to 65°C.
Does the DT4256 support PC data logging?
Yes. Optional USB communications can be used for PC-based data logging.
How much does the DT4256 weigh?
The DT4256 weighs 390 g and measures 84 × 174 × 52 mm.
Should I choose the DT4256 or DT4252?
Both are DT4200-series digital multimeters. The DT4252 can be considered when its measurement configuration better matches the intended application.
How can I check pricing for the DT4256?
Pricing is quote-based. Call +971 6 5436933 for current pricing and stock information.
Does GeneralTech Shop deliver the DT4256 across the UAE?
Call +971 6 5436933 and our team can confirm delivery availability and timelines for your emirate.
