HIOKI DATA COLLECTOR LR5092

Name: HIOKI DATA COLLECTOR LR5092
Brand: Hioki
SKU: LR5092
Availability: OutOfStock

Part Number : LR5092

The Hioki LR5092 is a data collector for wirelessly collecting data from the LR5000 Series Data Loggers. Simply dock the Data Collector onto the data logger to transfer data using infrared, then upload the data to a PC using USB or SD card. A maximum of 60,000 data x 16 channels can be collected up to 500 times on 2 batteries.

Availability: in stock

Specifications
Features
Downloads

communication	Between data loggers: Infrared communications With PC: USB 2.0
Dimensions (mm)	91 mm (3.58 in) W ƒ- 141 mm (5.55 in) H ƒ- 31 mm (1.22 in) D, 215 g (7.6 oz) (excluding batteries and SD memory card)
Display	Data logger setting conditions Collected data (as list, graph, values, etc.)
Functions	Send data from a data logger to the internal memory or an SD card, then display a graph. Send settings and the time from the internal memory or SD card to a data logger. Send data from a data logger to a PC. Send settings and the time from a PC to a data logger.
Internal Memory	60,000 data elements ƒ-16ch (instantaneous value mode) 15,000 data elements ƒ-16ch (statistical value mode) Data logger settings (max. 1 set)
Power Supply	DC 3 V (LR6 (AA) Alkaline battery ƒ-2) USB bus power (12 hours or 500 times of data collection)
