Flexbar 16356 | Chamfer Gauge | 90-127°, 25-50 mm
Part Number : 16356
For tapered holes and chamfers between 25-50 mm in diameter, Flexbar offers the 16356 chamfer gauge in its 90-127° range. The diameter is read straight off the dial, in metric units to 0.01 mm, which makes it a quick tool for checking countersinks during production.
Key features
- Capacity 25-50 mm, angle range 90-127°
- Direct diameter reading to 0.01 mm
- Hardened, precision-ground three-blade steel plunger for repeatable readings
- Zeroed on a surface plate; no setting masters needed
- For tapered holes whose included angle is less than the angle printed on the dial
To measure, hold the gauge just above the large body diameter, insert the plunger into the hole, press firmly against the part and twist slightly to centre it.
For pricing, please contact our experts.
