Flexbar 16345 | Chamfer Gauge | 0-90°, 0-25 mm
Part Number : 16345
For tapered holes and chamfers between 0-25 mm in diameter, Flexbar offers the 16345 chamfer gauge in its 0-90° range. The diameter is read straight off the dial, in metric units to 0.01 mm, which makes it a quick tool for checking countersinks during production.
Key features
- Capacity 0-25 mm, angle range 0-90°
- Direct diameter reading to 0.01 mm
- Hardened, precision-ground three-blade steel plunger for repeatable readings
- Zeroed on a surface plate; no setting masters needed
- For tapered holes whose included angle is less than the angle printed on the dial
To measure, hold the gauge just above the large body diameter, insert the plunger into the hole, press firmly against the part and twist slightly to centre it.
For pricing, please contact our experts.
