Dwyer Instruments MVB-WF4 | Mini Brass Ball Valve | Wedge handle | 450 psi | 1/2"
The Dwyer MVB-WF4 is a 1/2" mini brass ball valve with a wedge handle and female x female NPT connections, designed for compact shutoff applications where installation space is limited. Its PTFE ball seats provide bubble-tight shutdown, while the double seal mechanism allows bidirectional installation. Genuine Dwyer stock at General Tech Services LLC, UAE. Free UAE-wide shipping.
Request a quote in under a minute - call +971 6 5436933.
Part No. MVB-WF4 |
The Dwyer MVB-WF4 is a compact 1/2" mini brass ball valve designed for tight locations where a standard-size valve may be difficult to install. It features female x female NPT process connections and a wedge handle for straightforward manual operation.
The valve uses a chrome-plated brass body and ball for compact and durable construction. A fluoroelastomer O-ring provides the stem seal, while pure PTFE ball seats provide bubble-tight shutdown and broad media compatibility.
A double seal mechanism enables bidirectional operation, allowing the valve to be installed in either direction within the line. This provides greater installation flexibility for panels, skids, instrumentation systems, and utility piping.
Rated for 450 psi CWP, with an operating pressure range from -29" Hg vacuum to 450 psi (31 bar), the MVB-WF4 is suitable for compressed air, instrumentation, and general utility shutoff applications.
Key Benefits
- Compact 1/2" mini valve body for tight panel and skid locations
- Female x female NPT connections for straightforward installation
- Pure PTFE ball seats provide bubble-tight shutdown
- Double seal mechanism enables bidirectional installation
- Chrome-plated brass body and ball provide durable construction
- Wedge handle enables straightforward manual operation
- 450 psi CWP pressure rating
- Suitable for compressed air, instrumentation, and general utility shutoff
- Genuine Dwyer stock with free UAE-wide shipping
Who This Product Is Best For
- Panel and skid installations where available space is limited
- Compressed air systems requiring compact manual shutoff
- Instrumentation applications requiring a compact NPT ball valve
- General utility shutoff applications
- Installations where bidirectional valve positioning provides greater flexibility
How to Specify & Commission It
- Confirm the MVB-WF4's 1/2" size and female x female NPT connections match your fittings.
- Install the valve in either flow direction, using the bidirectional capability provided by the double seal mechanism.
- Operate the wedge handle to fully open or close the valve.
- Check the installation for leakage and verify proper shutoff before pressurising the complete system.
Frequently Asked Questions
What size is the MVB-WF4?
The MVB-WF4 is a 1/2" mini brass ball valve with female x female NPT end connections.
What is the maximum pressure rating?
The valve is rated to 450 psi CWP, with an operating pressure range from -29" Hg vacuum to 450 psi (31 bar).
Can the MVB-WF4 be installed in either flow direction?
Yes. The double seal mechanism allows bidirectional operation, so the valve can be installed in either direction.
What handle style does the valve use?
The MVB-WF4 uses a wedge handle for manual operation.
What materials are wetted by the process media?
The valve body and ball are chrome-plated brass, the stem seal is fluoroelastomer, and the ball seats are PTFE.
What applications is the MVB-WF4 suitable for?
It is suitable for compressed air, instrumentation, and general utility shutoff applications, particularly where installation space is limited.
Is genuine Dwyer stock available with UAE shipping?
Yes. Genuine Dwyer stock is available from General Tech Services LLC, UAE, with free UAE-wide shipping. Call +971 6 5436933 for pricing and current availability.
