Dwyer Instruments MV5-SM1 | Mini Brass Ball Valve | Screwdriver slot | 1/8" pipe size
The Dwyer MV5-SM1 is a 1/8" mini brass ball valve with a screwdriver slot handle and male x female NPT connections, designed for compact shutoff applications where installation space is limited. Its PTFE ball seats provide bubble-tight shutdown, while the double seal mechanism allows bidirectional installation. Genuine Dwyer stock at General Tech Services LLC, UAE. Free UAE-wide shipping.
Request a quote in under a minute - call +971 6 5436933.
Part No. MV5-SM1
The Dwyer MV5-SM1 is a compact 1/8" mini brass ball valve designed for tight spaces where a standard-size valve may be difficult to install. It features male x female NPT process connections and a screwdriver slot handle for straightforward manual operation.
The valve uses a chrome-plated brass body and ball for compact and durable construction. A fluoroelastomer O-ring provides the stem seal, while pure PTFE ball seats provide bubble-tight shutdown and broad media compatibility.
A double seal mechanism allows bidirectional operation, meaning the valve can be installed in either direction within the line. This provides greater installation flexibility for panels, skids, instrumentation systems, and utility piping.
Rated for 450 psi CWP, with an operating pressure range from -29" Hg vacuum to 450 psi (31 bar), the MV5-SM1 is suitable for compressed air, instrumentation, and general utility shutoff applications.
Key Benefits
- Compact 1/8" mini valve body for tight panel and skid locations
- Male x female NPT connections simplify installation
- Pure PTFE ball seats provide bubble-tight shutdown
- Double seal mechanism enables bidirectional installation
- Chrome-plated brass body and ball provide durable construction
- Screwdriver slot handle enables straightforward manual operation
- 450 psi CWP pressure rating
- Suitable for compressed air, instrumentation, and general utility shutoff
- Genuine Dwyer stock with free UAE-wide shipping
Who This Product Is Best For
- Panel and skid installations where available space is limited
- Compressed air systems requiring compact manual shutoff
- Instrumentation applications requiring a small NPT ball valve
- General utility shutoff applications
- Installations where bidirectional valve positioning provides greater flexibility
How to Specify & Commission It
- Confirm the MV5-SM1's 1/8" size and male x female NPT connections match your fittings.
- Install the valve in either flow direction, using the bidirectional capability provided by the double seal mechanism.
- Operate the screwdriver slot handle to fully open or close the valve.
- Check the installation for leakage and verify proper shutoff before pressurising the complete system.
Frequently Asked Questions
What size is the MV5-SM1?
The MV5-SM1 is a 1/8" mini brass ball valve with male x female NPT end connections.
What is the maximum pressure rating?
The valve is rated to 450 psi CWP, with an operating pressure range from -29" Hg vacuum to 450 psi (31 bar).
Can the MV5-SM1 be installed in either flow direction?
Yes. The double seal mechanism allows bidirectional operation, so the valve can be installed in either direction.
What handle style does the valve use?
The MV5-SM1 uses a screwdriver slot handle for manual operation.
What materials are wetted by the process media?
The valve body and ball are chrome-plated brass, the stem seal is fluoroelastomer, and the ball seats are PTFE.
What applications is the MV5-SM1 suitable for?
It is suitable for compressed air, instrumentation, and general utility shutoff applications, particularly where installation space is limited.
Is genuine Dwyer stock available with UAE shipping?
Yes. Genuine Dwyer stock is available from General Tech Services LLC, UAE, with free UAE-wide shipping. Call +971 6 5436933 for pricing and current availability.
