Desoutter Socket-SQ3/8-L50-HEX10-M-R-TW | 3/8" Square Drive Rotaction Socket | 10 mm, Hexagon, 50 mm
The Desoutter Socket-SQ3/8-L50-HEX10-M-R-TW (part number 4027128510) is a 3/8" Square Drive Rotaction Socket with output 10 mm, output type Hexagon and length l 50 mm. Output profile, length, torque rating and the matching socket cover reference for each socket are listed in the specification table.
Key features
- Output: 10 mm
- Output type: Hexagon
- Length L: 50 mm
- Max torque: 54 N*m
- Works with Rotaction tool and socket covers
- Rotaction freely rotating sleeve design
- Specifications
- Downloads
| Part Number | 4027128510 |
| Model | Socket-SQ3/8-L50-HEX10-M-R-TW |
| Brand | Desoutter |
| Output | 10 mm |
| Output type | Hexagon |
| Length L | 50 mm |
| Max torque | 54 N*m |
| Output D | 17.8 mm |
| Profile depth T | 4.2 mm |
| Input | 3/8" |
| Input d | 22 mm |
| Features | Magnet||Rotaction||Thin walled |
| Socket cover reference | C22 |
| Weight | 62 g |
