Desoutter Socket-SQ3/4-L55-DHEX36 | 3/4" Square Drive Power Socket | 36 mm, 55 mm
The Desoutter Socket-SQ3/4-L55-DHEX36 (part number 4027151536) is a 3/4" Square Drive Power Socket with output 36 mm, output type Double hexagon and length l 55 mm. Each socket has a female square drive at the input end and an output profile sized to the fastener, as shown in the specification table.
Key features
- Output: 36 mm
- Output type: Double hexagon
- Length L: 55 mm
- Max torque: 1540 N*m
- Part of a standard range of over 2,600 bits and sockets
- Custom-fit versions offered by the manufacturer for special needs
- Specifications
- Downloads
| Part Number | 4027151536 |
| Model | Socket-SQ3/4-L55-DHEX36 |
| Brand | Desoutter |
| Output | 36 mm |
| Output type | Double hexagon |
| Length L | 55 mm |
| Max torque | 1540 N*m |
| Output D | 53.8 mm |
| Profile depth T | 20 mm |
| Input | 3/4" |
| Input d | 44 mm |
| Weight | 498 g |
