Desoutter Socket-SQ3/4-L50-SD18-R | 3/4" Square Drive Rotaction Socket | 18 mm, Surface drive, 50 mm
The Desoutter Socket-SQ3/4-L50-SD18-R (part number 4027151118) is a 3/4" Square Drive Rotaction Socket with input 3/4", output 18 mm and output type Surface drive. Because the outer sleeve rotates freely, the 3/4" square drive socket lowers the risk of entanglement for the operator during tightening.
Key features
- Input: 3/4"
- Output: 18 mm
- Output type: Surface drive
- Length L: 50 mm
- Minimises the risk of entanglement
- Enhanced tool control with ROTACTION tool and socket covers
- Specifications
| Part Number | 4027151118 |
| Model | Socket-SQ3/4-L50-SD18-R |
| Brand | Desoutter |
| Input | 3/4" |
| Output | 18 mm |
| Output type | Surface drive |
| Length L | 50 mm |
| Max torque | 924 N*m |
| Features | Rotaction |
| Socket cover reference | C47 |
| Output D | 34.3 mm |
| Input d | 47 mm |
| Weight | 398 g |
| Profile depth T | 13 mm |
