Desoutter Socket-SQ3/4-L100-DHEX16 | 3/4" Square Drive Power Socket | 16 mm, 100 mm
The Desoutter Socket-SQ3/4-L100-DHEX16 (part number 4027151716) is a 3/4" Square Drive Power Socket with output 16 mm, output type Double hexagon and length l 100 mm. Where a standard part does not fit the job, Saltus states that sockets can be custom made to suit a specific application.
Key features
- Output: 16 mm
- Output type: Double hexagon
- Length L: 100 mm
- Max torque: 600 N*m
- Custom-fit versions offered by the manufacturer for special needs
- 3/4" square drive input
- Specifications
- Downloads
| Part Number | 4027151716 |
| Model | Socket-SQ3/4-L100-DHEX16 |
| Brand | Desoutter |
| Output | 16 mm |
| Output type | Double hexagon |
| Length L | 100 mm |
| Max torque | 600 N*m |
| Output D | 28.8 mm |
| Profile depth T | 16 mm |
| Input | 3/4" |
| Input d | 44 mm |
| Weight | 524 g |
