Dakota F-000-7104 | Acrylic Delay Line Tip | 3/8 x 1/2 in

Name: Dakota F-000-7104 | Acrylic Delay Line Tip | 3/8 x 1/2 in
Brand: Dakota Ultrasonics
SKU: F-000-7104
Availability: OutOfStock

Part Number : F-000-7104

This Dakota delay line tip, part number F-000-7104, is a 3/8 in dia x 1/2 in long tip in acrylic. By slowing the sound pulse from a single element transducer, the tip makes accurate measurement of thinner sections possible. Acrylic is Dakota's choice for steel, aluminium and titanium, measured in interface-echo or echo-echo mode.

Key features

Size: 3/8 in dia x 1/2 in long
Material: Acrylic
Type: Delay Line Tip

Availability: in stock

Specifications

Part Number	F-000-7104
Brand	Dakota Ultrasonics
Size	3/8 x 1/2 in
Dimensions	3/8 in dia x 1/2 in long
Type	Delay Line Tip
Material	Acrylic
