Dakota F-000-7103 | Acrylic Delay Line Tip | 1/4 x 1/2 in

Name: Dakota F-000-7103 | Acrylic Delay Line Tip | 1/4 x 1/2 in
Brand: Dakota Ultrasonics
SKU: F-000-7103
Availability: OutOfStock

Part Number : F-000-7103

Part number F-000-7103 is Dakota's 1/4 in dia x 1/2 in long delay line tip made from acrylic. Delay lines go on single element transducers and slow the sound pulse, which allows precise readings on thin material. Being acrylic, it is the type to use on steel, aluminium and titanium in interface-echo or echo-echo mode.

Key features

Size: 1/4 in dia x 1/2 in long
Material: Acrylic
Type: Delay Line Tip

Availability: in stock

Specifications

Part Number	F-000-7103
Brand	Dakota Ultrasonics
Size	1/4 x 1/2 in
Dimensions	1/4 in dia x 1/2 in long
Type	Delay Line Tip
Material	Acrylic
