CONCOA 8069445-01-1 | 9400 Series Dual Stage Regulator | Carbon Dioxide, CGA 320, 40 PSIG Delivery
Part Number : 8069445-01-1
This 9400 Dual Stage Regulator, CONCOA 8069445-01-1, takes carbon dioxide through a CGA 320 connection and delivers up to 40 PSIG (3 BAR) at a 5/8 in -18 (B) RH Int outlet. It carries 0-60 PSIG/0-400 kPa and 0-4000 PSIG/0-28,000 kPa gauges. Fine adjustment from its dual stage design makes the 8069445-01-1 suit high-precision industrial applications.
Key features
- Heavy forged brass bonnet and 25-micron glass wool filter with sintered Monel® screens
- Forged brass body; cleanliness to CGA G-4.1 or better
- 2 1/2 in (63 mm) brass gauges, plus 3000 PSIG (210 BAR) maximum inlet
For pricing, please contact our experts.
