CONCOA 8066773-01-1 | 6700 Series Manifold Regulator | Inert Gas, 120 PSIG Delivery, LH Inlet
Part Number : 8066773-01-1
Part 8066773-01-1 is the LH-inlet 6700 Series manifold regulator set up for inert gas. An FKM seat controls delivery pressure up to 120 PSIG (8 BAR), shown on 0-200 PSIG/0-1400 kPa and 0-4000 PSIG/0-28,000 kPa gauges.
Key features
- A rugged forged brass bonnet and a Cv of 2.0
- A 40-micron 316L stainless steel filter with a balanced stem seat that steadies output as inlet pressure decays
- A chloroprene diaphragm and 1/2 in FNPT inlet and outlet ports
- 2 1/2 in (63 mm) brass gauges, plus 1/4 in FNPT gauge and relief ports
For pricing, please contact our experts.
