CONCOA 8066592-01-1 | 6590 Series Pipeline Regulator | Acetylene/Fuel Gas, CGA 025, 15 PSIG Delivery
CONCOA 8066592-01-1 | 6590 Series Pipeline Regulator | Acetylene/Fuel Gas, CGA 025, 15 PSIG Delivery
Part Number : 8066592-01-1
CONCOA 8066592-01-1 is the acetylene and fuel gas point-of-use pipeline regulator of the 6590 Series Pipeline Regulator line, with a CGA 025 inlet and a 9/16 in -18 (B) LH Ext outlet. Delivery pressure is adjustable up to 15 PSIG (1 BAR) and the outlet gauge reads 0-30 PSIG/0-200 kPa.
Key features
- A 200 PSIG (14 BAR) maximum inlet pressure, plus a forged brass body
- A chrome-plated, die-cast zinc bonnet and a chloroprene diaphragm for steady pressure control
- An encapsulated CAPSULE® seat that is simple to service, plus medium-large seat displacement for high flow capacity
- A 2 1/2 in (63 mm) brass gauge, plus a 25-micron sintered bronze inlet filter
For pricing, please contact our experts.
