CONCOA 8065575-01-1 | 5500 Series Flowmeter Regulator | Argon, Helium, CGA 580, 30 PSIG Preset
Part Number : 8065575-01-1
Configured as a 30 PSIG preset delivery pressure unit, the CONCOA 8065575-01-1 flowmeter regulator serves argon, helium cylinders through a CGA 580 inlet with a PTFE seat, rated to 3000 PSIG (210 BAR). Metering: 10-60 SCFH Argon/30-200 SCFH Helium Flowmeter and 0-4000 PSIG/0-28,000 kPa Inlet Gauge. Use 8065575-01-1 for primary cylinder flow control where a preset 30 PSIG delivery suits the process.
Key features
- Forged brass body and chrome-plated, die-cast zinc bonnet on 8065575-01-1
- 8065575-01-1 uses a chloroprene diaphragm for steady control
- Medium-large seat displacement gives 8065575-01-1 good flow capacity
- Outlet of 8065575-01-1: 5/8 in -18 (B) RH Int; filter: 25-micron sintered bronze
For pricing, please contact our experts.
