CONCOA 622 Series | Dome-Loaded Regulator | Up to 5200 SCFH Nitrogen, 1/2 in FNPT
Part Number : CONCOA-622-SERIES-DOME-LOADED-REGULATOR
The CONCOA 622 Series is a dome-loaded purge regulator assembly with a single-body design, handling nitrogen flows up to 5200 SCFH (2454 lpm). It is aimed at high-flow gas delivery in laboratory and industrial systems where stable, sensitive pressure control is needed.
CONCOA configures the 622 Series to order, so outlet range, gauges, connections and options are set at purchase; the source names a 600, 3000 or 4500 PSIG maximum inlet, right or left-hand inlets and an optional wall/panel mounting kit.
- 40-micron sintered bronze internal filter
- CAPSULE® seat for longer service life
- Brass barstock body and bonnet
- 316L stainless steel tube and fittings
- 1/2 in FNPT inlet and outlet, 2 in (50 mm) brass gauges
- Cleaned for oxygen service
For pricing, please contact our experts.
