CONCOA 5338052-01-001 | 533 Series High Flow Diaphragm Valve | 1/2 in Tube Stub x 1/2 in FNPT, 0.30 Cv
Part Number : 5338052-01-001
With 1/2 in tube stub x 1/2 in FNPT inlet/outlet ends, the CONCOA 5338052-01-001 diaphragm valve gives 0.30 Cv of flow capacity from the 533 high flow family. Part 5338052-01-001 is rated to 3500 PSIG (240 BAR) at the inlet and the same differential back pressure. Specify 5338052-01-001 for primary or pipeline control of high purity or corrosive gases.
Key features
- Elgiloy® diaphragm and metal-to-metal sealing in valve 5338052-01-001
- PCTFE seat gives valve 5338052-01-001 positive shut-off
- Valve 5338052-01-001: helium leak integrity 2 x 10⁻⁸
- Cleanroom assembled; cleanliness of valve 5338052-01-001 meets or exceeds CGA G-4.1
For pricing, please contact our experts.
