Brannan 35/506/1 | Stainless Fillable Pressure Gauge | 100 mm, 0 to 230 psi, bottom 1/2" BSP, dry, 1.0%
Part Number : 35/506/1
Brannan 35/506/1 is a 100 mm (4") stainless steel pressure gauge reading 0 to 230 psi on a dual psi outer (red) and bar inner (black) scale, with a bottom 1/2" BSP brass connection and 1.0% accuracy class, supplied dry. It belongs to the PG030 general industrial range, whose waterproof, corrosion resistant 304 stainless steel case suits HVAC, outdoor and high humidity installations, pneumatics, hydraulics and machine construction.
Key features
- Stainless steel 304 case with brass connection, IP 65
- Phosphor bronze Bourdon tube, designed to BS EN 837 / ASME B40.100
- Micro adjustable pointer, tempered glass window and bayonet bezel on the 1.0% class
- Front or back flange available for panel mounting
- Accessories include syphon, needle valve, gauge cock and snubber
Brannan can supply this gauge with UKAS certification, a certificate traceable to a recognised national standard or a statement of conformity.
For pricing, please contact our experts.
