ASCO PROFILED CYLINDERS ˜ 32 to 100 mm - double acting ISO 15552-AFNOR-DIN high temperature Series 453/Type PES P-A-HT/PES P-A-HT-T2
Part No. Series 453 PES-P-A-HT
ASCO Series 453 profiled-barrel cylinders with high-temperature construction are double-acting ISO 15552 (AFNOR/DIN) actuators available in 32 to 100 mm bores for industrial automation. The PES-P-A-HT configuration is designed for applications where elevated temperatures can affect standard cylinder sealing materials. Genuine ASCO cylinder, supplied in the UAE by General Tech Services LLC. Pricing is quote-based. Request a quote in under a minute - call +971 6 543 6933.
The Series 453 PES-P-A-HT uses a profiled aluminium barrel and materials selected for high-temperature applications. It is intended for environments such as ovens, dryers, moulding equipment and other hot processes where standard cylinder seals may be unsuitable.
The profiled barrel includes integrated grooves for position detectors such as ASCO Series 494, allowing end-of-stroke feedback devices to be installed without additional brackets. Double-acting operation provides controlled force and movement in both directions.
ISO 15552 (AFNOR/DIN) dimensions allow the cylinder to use standard ISO mountings, rod ends and guiding units. When sizing the cylinder, consider the required force, available working air pressure, stroke, friction and dynamic loads. Long strokes with side loads may require a guiding unit. Share the bore, stroke, mounting and application details with our team for code and accessory confirmation.
For applications where chemical resistance rather than high-temperature performance is the main requirement, the Series 450/453 FPM cylinder configuration uses FPM seals.
Ready to order the ASCO Series 453 PES-P-A-HT? Speak to our team. Call +971 6 543 6933
Key Benefits
-
ISO 15552 (AFNOR/DIN) dimensions for compatible replacement applications
-
32 to 100 mm bore range
-
Double-acting pneumatic operation
-
High-temperature construction for hot-process applications
-
Profiled aluminium barrel with integrated sensor grooves
-
Compatible with standard ISO mountings, rod ends and guiding units
-
Suitable for ovens, dryers, moulding and heat-treatment applications
-
Genuine ASCO cylinder supplied in the UAE by General Tech Services LLC
Who This Product Is Best For
-
Ovens, dryers and hot-process equipment
-
Glass, metal and plastics processing applications
-
Moulding and heat-treatment lines
-
Curing and industrial heating systems
-
Applications where elevated temperatures can affect standard cylinder seals
-
OEMs and maintenance teams sourcing ISO 15552 cylinders in the UAE
How to Install & Use It
-
Confirm the required bore, stroke, mounting arrangement and operating temperature.
-
Select suitable ISO 15552 mountings, rod ends and guiding accessories.
-
Install compatible Series 494 position detectors in the barrel grooves if end-of-stroke feedback is required.
-
Connect the appropriate compressed-air supply and pneumatic controls.
-
Set the operating speed and test cylinder movement under the expected load and temperature conditions.
-
Verify the complete assembly before placing the equipment into normal operation.
Frequently Asked Questions
What is the ASCO Series 453 high-temperature cylinder?
It is a double-acting ISO 15552 (AFNOR/DIN) profiled-barrel pneumatic cylinder available in 32 to 100 mm bores with high-temperature construction.
What is the PES-P-A-HT configuration designed for?
The PES-P-A-HT configuration is designed for applications where elevated temperatures require cylinder materials and sealing suitable for hot operating environments.
Is the Series 453 interchangeable with other ISO cylinders?
The Series 453 follows ISO 15552 (AFNOR/DIN) dimensions for mounting and rod-end compatibility. Confirm the exact bore, stroke, mounting and application requirements before replacement.
Can I add position sensors to the Series 453?
Yes. The profiled barrel has integrated grooves for position detectors such as ASCO Series 494.
Which bore and stroke do I need?
Bore selection depends on the required force and available working air pressure, while stroke depends on the required travel. Share the load, speed and travel requirements with General Tech Services LLC for sizing assistance.
How do I calculate the required cylinder bore?
Cylinder bore is selected according to the required force and working air pressure, with allowance for friction and dynamic loads. General Tech Services LLC can assist with the sizing calculation when you provide the application data.
Is there an alternative version for aggressive chemicals?
The Series 450/453 FPM cylinder configuration uses FPM seals and is intended for a different duty. Confirm the required configuration and application compatibility with General Tech Services LLC.
How do I choose the Series 453 or another ISO cylinder?
Choose the cylinder based on bore, stroke, mounting dimensions, operating pressure, load, speed, temperature, environment and seal requirements. Send your application details and cylinder code to General Tech Services LLC for compatibility confirmation.
How do I get a price and lead time?
Pricing is quote-based. Call General Tech Services LLC on +971 6 543 6933 or submit the Request a Quote form.
Is this a genuine ASCO cylinder?
General Tech Services supplies original ASCO cylinders in the UAE with technical support.
For pricing or to place an order, contact General Tech Services LLC. Call +971 6 543 6933.
