Mitutoyo 115-303 | Tube Micrometer | 25–50 mm, Pin Anvil
Part Number : 115-303
With a pin anvil and flat spindle and a measuring range of 25–50 mm, the 115-303 is an analogue tube micrometer from Mitutoyo reading in 0.01 mm steps. The 115-303 is meant for curved parts, including the walls of tubes, rings and bearings. Because its range starts at 25 mm, the 115-303 ships with a setting standard.
- Carbide-tipped spindle with micro-lap finish, hardened steel anvil on the 115-303
- Measuring force 3–8 N, flatness 0.6 µm on the 115-303
- Spindle lock, Ø6.35 mm spindle, 0.5 mm pitch (115-303, 25–50 mm)
- Satin-chrome thimble and sleeve, Ø18 mm (115-303)
- Supplied with box, setting standard and key; main unit mass 240 g for the 115-303
For pricing, please contact our experts.
